SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

Name: SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing
Brand: Lijiang
Price: 1 USD

Quality SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing for sale

Brand Name : Lijiang

Model Number : LJTB01

Certification : CE UL

Place of Origin : CHINA

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, T/T, MoneyGram, Western Union

Supply Ability : 20 sets per month

Delivery Time : 3days

Packaging Details : WOODEN BOX OR PLASTIC FILM

Name : Butyl coated Machine

Aluminum Spacer width : 6A-30A

Coating pressure : 10-18mpa

Coating temperature : 110-140 °

Total power : 5.7kw

machine size : 2800*700*900mm

coating speed : 0-47m/min

butyl plug weight : 7kg-50kg

Contact Now

47m/Min 5.7kw 18mpa Extrusion Coating Machine Insulating Glass Machine

SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

Butyl extruder parameters

Name	Brand	Original
PLC	KINCO	China
Valve	HAWE	German
Low voltage electrical apparatus	SIEMENS	German
Hydraulic and pneumatic supercharging system	MAXIMATOR	German
Frequency converter	KINCO	China
Pneumatic components(cylinder/valve)	ARTAC	Taiwan
Quick exhaust valve/Vacuum generator	SMC	Japan SMC
Travel light	OMRON	Japan
Optical fiber	OMRON	Japan

Squeeze pressure	10-18MPa
Temperature	110~140℃
Aluminum spacer width	4-30mm
Speed	0-47m/min
Diameter of butyl cylinder	200mm
Air supply	0.4m³/min
Air pressure	≥0.6MPa
Total power	380V, 5KW, 50HZ
Dimension	2600×680×1100mm(L×W×H)
Weight	650kg

Butyl Extruder Machine

Main Features:

• PLC control system, touch screen interface • Automatically identify the width of aluminum bar, the glue nuzzle can be automatic adjust • The critical part of the hydraulic system using German imports of components to ensure that the plastic evenly full • Fast preheat, improve work efficiency • with preheating function • With exhaust inflatable function, improve the quality of sealing and save time for plastic • Quickly coating speed,can up to 47m/min • Saving the amount of glue

Details Images

Technical data

SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

Electrical parameters

SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

Service Team:

We have our own china domestic team and oversea service team .

Whole team was included by 15 china engineers who worked in glass machine filed more than 20 years and 5 oversea engineers ,

two of them from india and others from south America and midle east.

24 hours online service and local engineer available , guarantee customers got timely service and solution .
